Regular price $135.00 $0.00 Unit price per
free shipping over $299
FEDEX 3-5 days delivered

Specifications and Downloads

  • 8" Internal width galvanized stamped steel ADA package
  • Two channel depth options - 3 inch and 8 inch
  • Comes with steel grate, channel, brackets and end caps
  • Heavy duty load rated
  • Connect multiple channels for longer run
  • 3" and 4" PVC or corrugated pipe bottom outlet options
  • 4" PVC or corrugated pipe options out of the included end caps on the 8" depth option
  • More product details below
  • grating specification pdf
  • 3 inch channel depth pdf
  • 3 inch channel depth cad
  • 8 inch channel depth pdf
  • 8 inch channel depth cad
  • installation brochure

Product Description

Standartparks 8 inch Galvanized Stamped Steel ADA channel package comes with one channel with the depth of your choice. Our high end A Class Galvanized Stamped Steel Grating, fasteners and end caps. On the 3" channel depth option you have a 4 and 6 inch bottom outlet. On the 8" Channel Depth option , the channel is fitted with a 4" out of the end cap, 4 and 6 inch out of the bottom, as well as a 4" out of the side of the system. 90 degree turns are already fitted on to the channel itself as well, so no adapters are needed.

 PARAMETERS

Article Numbers;

8" Depth - PC 8540

3" Depth - PC 8510

Galvanized Grate - GG2510-ADA

Material ................... PPE PLASTIC / Galvanized Steel

Load Class .............. A Class - 3,300 lbs - Pedestrian Rated

INCLUDED IN PACKAGE

1 Unit - Channel Depth of Choice

1 Unit - Galvanized Stamped Steel

2 Units - Grating Fasteners

- End Caps (Per Order) - Additional end caps at checkout.
