Specifications and Downloads
- 4" Internal width stainless steel B class ADA Package
- Comes with stainless steel grate, channel, brackets and end caps
- Vehicle load rated, ADA Compliant
- Connect multiple channels for longer run
- 4" PVC or corrugated pipe bottom outlet option on each channel
- 4" PVC or corrugate pipe outlet option out of end caps (on the 6" and 8" channel depth options)
- More product details below
This package is fitted with our ADA approved Stainless Steel B CLASS grating which has a weight load rating at 27,500 lbs. Making it available to drive over as well as forklift rated as well. Perfect for around a pool / chemical plant / or where you want to make sure you receive NO corrosion ever on your gratings. The stainless steel is a matte finished polish - not a shine. Nice rich look / feel as well. Comes with end caps, channel brackets for fastening grating down tight, and of course the channel itself.
Each channel is 3.3 ft in length, with a tongue and groove connection so you can attach end to end to create a longer and custom size run. In addition, each channel has a 90 degree turn already within the system - no adapters needed! Please see below for outlet specs per channel depth.
2" Depth - PC8050 - 4" bottom outlet
3" Depth - PC8010 - 4" bottom outlet
4" Depth - PC8020 - 4" bottom outlet
6" Depth - PC8000 - 4" bottom outlet - 4" end cap outlet
8" Depth - PC8040 - 4" bottom outlet - 4" end cap outlet
Material ............. PPE Plastic
Dimensions ....... 39.4"L x 5.8"W
Load Class ....... B Class - 27,500 LBS
INCLUDED IN PACKAGE
1 - Channel Depth of Choice
1 - Unit of Stainless Steel B Class Grating
2 - Grating Fasteners
2 - End Caps (Per Order) - Additional end caps at checkout.
